Original: $1,094.06
-65%$1,094.06
$382.92The Story
On Demo Now!
Click Here to Book an In-Store Demo!
The Rotel A12MKII Integrated Amplifier packs all your favorite audio sources into one dynamic and compact package. Delivering 60 watts of Class AB output into 8 ohms, this amplifier offers crystal-clear sound reproduction thanks to its optimized circuits and 32-bit DAC. Enjoy MM Phono Stage, analog, digital, PC-USB, and wireless Bluetooth with the A12MKII.
| Continuous Power Output - 8 Ohms |
60 W/Ch |
| Maximum Power Output - 4 Ohms | 120 W/Ch |
| Speaker A/B | Yes |
| Amplifier Class | AB / Custom Designed Toroidal Transformer |
| Total Harmonic Distortion | < 0.018% |
| Analog Inputs |
|
| Digital Inputs |
|
| Outputs |
|
| DAC (Digital to Analog Converter) | Texas Instruments 32-bit / 384kHz |
| Frequency Response - Phono Input | 20-20kHz (0 +/- 0.5dB) |
| Frequency Response - Line Level Inputs |
10-100kHz (0 +/- 0.5dB) |
| Frequency Response - Digital Inputs | 10-90kHz (0 +/- 2dB, Max) |
| Damping Factor | 220 (20-20kHz 8 Ohms) |
| Input Sensitivity / Impedance - Phono Input MM |
3.4mV / 47k Ohms |
| Input Sensitivity / Impedance - Line Level Inputs RCA |
230mV / 24k Ohms |
| Input Sensitivity / Impedance - Digital Inputs |
0dBfs / 75 Ohms |
| Preamp Output / Impedance | 1.2V / 470 Ohms |
| Signal to Noise Ratio - Phono Input (MM) | 90dB |
| Signal to Noise Ratio - Line Level Imputs | 100dB |
| Signal to Noise Ratio - Digital Inputs |
103dB |
| Available Sample Rates - Coaxial / Optical | 24-bit / 192kHz |
| Available Sample Rates - PC-USB |
|
| Power Consumption - Normal | < 0.5 Watts |
| Dimensions (WxHxD) | 17" x 3 5/8" x 13 1/2" (430mm x 93mm x 345mm) |
| Panel Height | 3 1/8" (80mm) |
| Weight | 19.31lbs (8.76kg) |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
On Demo Now!
Click Here to Book an In-Store Demo!
The Rotel A12MKII Integrated Amplifier packs all your favorite audio sources into one dynamic and compact package. Delivering 60 watts of Class AB output into 8 ohms, this amplifier offers crystal-clear sound reproduction thanks to its optimized circuits and 32-bit DAC. Enjoy MM Phono Stage, analog, digital, PC-USB, and wireless Bluetooth with the A12MKII.
| Continuous Power Output - 8 Ohms |
60 W/Ch |
| Maximum Power Output - 4 Ohms | 120 W/Ch |
| Speaker A/B | Yes |
| Amplifier Class | AB / Custom Designed Toroidal Transformer |
| Total Harmonic Distortion | < 0.018% |
| Analog Inputs |
|
| Digital Inputs |
|
| Outputs |
|
| DAC (Digital to Analog Converter) | Texas Instruments 32-bit / 384kHz |
| Frequency Response - Phono Input | 20-20kHz (0 +/- 0.5dB) |
| Frequency Response - Line Level Inputs |
10-100kHz (0 +/- 0.5dB) |
| Frequency Response - Digital Inputs | 10-90kHz (0 +/- 2dB, Max) |
| Damping Factor | 220 (20-20kHz 8 Ohms) |
| Input Sensitivity / Impedance - Phono Input MM |
3.4mV / 47k Ohms |
| Input Sensitivity / Impedance - Line Level Inputs RCA |
230mV / 24k Ohms |
| Input Sensitivity / Impedance - Digital Inputs |
0dBfs / 75 Ohms |
| Preamp Output / Impedance | 1.2V / 470 Ohms |
| Signal to Noise Ratio - Phono Input (MM) | 90dB |
| Signal to Noise Ratio - Line Level Imputs | 100dB |
| Signal to Noise Ratio - Digital Inputs |
103dB |
| Available Sample Rates - Coaxial / Optical | 24-bit / 192kHz |
| Available Sample Rates - PC-USB |
|
| Power Consumption - Normal | < 0.5 Watts |
| Dimensions (WxHxD) | 17" x 3 5/8" x 13 1/2" (430mm x 93mm x 345mm) |
| Panel Height | 3 1/8" (80mm) |
| Weight | 19.31lbs (8.76kg) |
